- Edge-enhanced steel frame for added structural strength.
- Black anodized voice coil former for superior heat dissipation.
- Linear double-roll surround for precision cone movement.
- Complex FEA-designed high-efficiency motor.
- Rigid poly mica-coated cone for optimized sound reproduction.
- Rear dampened hybrid silk dome tweeter for extended frequency response.
- High-quality mounting hardware included.
Experience the ultimate in-car sound performance with AudioControl's PNW Series 6.5" High-Fidelity Component Speakers. Designed to deliver premium sound quality and unmatched audio performance, these speakers will take your in-car audio to the next level. With features like an edge-enhanced steel frame for durability, a rigid poly mica-coated cone for optimized sound reproduction, and a complex FEA-designed high-efficiency motor for exceptional audio performance, these speakers deliver clear, powerful sound with every note and instrument. The rear-dampened hybrid silk dome tweeter ensures extended frequency response and outstanding clarity, reproducing every note with stunning accuracy. The high-quality mounting hardware makes installation a breeze, allowing seamless integration into any car. Upgrade your in-car audio experience and immerse yourself in the power of true, immersive sound with AudioControl's PNW Series 6.5" High-Fidelity Component Speakers.
What’s in the Box
- (2) 6.5″ High-Fidelity Component Speakers
- User Guide
- Mounting Diagram
|Crossover Type||2nd order Linkwitz-Riley|
|DC Resistance (Re)||2.3 ohms|
|Filter Type||HP / LP|
|System Frequency (Fs) Response||60-20k Hz|
|XO Frequency||3.5kHz HP / LP|
|Slope (Octave)||-12 dB|
|Tweeter Voice Coil Diameter||20 mm|
|Midrange Voice Coil Diameter||35 mm|
|Overall Diameter(w/o Metal bracket)||6.5 in / 166 mm|
|Cut Out Diameter||5.59 in / 142 mm|
|Mounting Depth||2.36 in / 60 mm|
|Mounting Height (w/o Grille)||0.20 in / 5.2 mm|
|Mounting Height (w/ Grille)||0.86 in / 22 mm|
|Motor Diameter (w/ Cover)||4.6 in / 117 mm|
|Grille Overall Diameter||7.05 in / 179 mm|
|Overall Diameter (G)||2.13 in / 54 mm|
|Cut Out Diameter (H)||1.85 in / 47 mm|
|Mounting Depth||0.63 in / 16 mm|
