Overview
Description
There’s no better time to switch out your Jeep Wrangler JK’s factory radio for the 6.8” Double DIN radio kit! Designed with a capacitive touch screen and allows you to retain factory features such as climate and steering wheel controls. This aftermarket head unit includes a factory-matched radio mounting dash kit with everything you need for an easy installation!
Features
-
Gain Total Access to your Smartphone: Compatible with Apple CarPlay and Android Auto (wired connection), to make it possible to access map navigation, phone contacts, emails, notifications, music, and much more.
-
HD Touch Screen and Bluetooth Function: 6.8” capacitive touch screen supports Bluetooth handsfree calling and auto streaming will give you a fantastic experience.
-
Experience Versatile and More Detailed Sound Experience: Allows for more audio enhancements than any factory radio.
-
Help Reduce Risk Rear Camera Inputs: The 6.8" radio kit allows for a rearview camera inputs and features adjustable guidelines.
-
Includes Everything you Need for Installation: Beautiful 6.8 inch touch screen, interface that retains OEM steering wheel controls, custom-fit dash kit, USB input extension, and an installation guide.
- Media Features: Android Auto, Apple CarPlay, hands-free Bluetooth, and customizable backgrounds/backlighting.
What's In The Box
- Multimedia 6.8 inch touch screen radio
- RadioPro Interface for Jeep Wrangler JK (2007-2018)
- Jeep Wrangler JK radio dash kit (CDK642)
- Antenna adapters for satellite and AM/FM radio
- Complete Plug-n-Play installation harness
- Hardware kits
- USB retention cable
- User Guide
Specifications
GENERAL
| Model Number | STGCD642RPDDB |
| Mounting Design | Double Din |
| Display Resolution | 1024 x 600 |
| Screen Size | 6.8" |
| Manufacturer's Warranty | 1 year |
| Operating Voltage | 14.vVDC(10.5-16V) |
| Operational Temperature | -20°C-+80°C |
| Max Current Consumption | 15A |
VIDEO
| Color System of External Video Input |
NTSC/PAL |
| External Video Input |
1 Vp-p/75Ω |
| Supporting Formats |
MPEG 1 (.mpg,mpeg), 720x480(30ps) |
AUDIO
| Maximum Power | 50Wx4 |
| Continuous Power Output | 22Wx4 |
| Preout Level (V) | 4V/10kΩ |
| Preout Impedance | ≤1.3kΩ |
| Speaker Impedance | 4-8Ω |
| Output Frequency Band | 20-20000Hz |
| Audio Formats |
MP3/WMA Bit rate: 16-320 Kbps, VBR WMA Version V9 or earlier ID3 Tag Version 1.0/1.1/2.2/2.3/2.4 |
RADIO
| Frequency FM Range | 87.5MHz to 107.9MHz |
| Frequency AM Range | 530MHz to 1710MHz |
| Usable Sensitivity |
13.2 uV (FM) |
USB
| USB Standard |
USB 2.0 Full Speed |
| File System |
FAT 16/32 |
| Maximum Current |
DC 5V ⎓ 1.5A |
| D/A Converter |
24Bit |
BLUETOOTH
| Communication System | Bluetooth Ver 4.1 |
| Output | Bluetooth Standard Power Class 2 |
| Maximum Communication Range | Approx. 10meters |
| Frequency Band | 2.4 GHz |
| Compatible Bluetooth Profiles | HFP/SPP/A2DP/AVRCP/PBAP |
| Supported Codecs | SBC (Sub Band Codec) |
Vehicle Fitment Guide
| Year(s) | Make | Model | Trim Level |
|---|---|---|---|
| 2011-2014 | CHRYSLER | 200 | ALL TRIM LEVELS |
| 2008-2010 | CHRYSLER | 300 | ALL TRIM LEVELS |
| 2008-2009 | CHRYSLER | ASPEN | ALL TRIM LEVELS |
| 2007-2010 | CHRYSLER | SEBRING | ALL TRIM LEVELS |
| 2008-2016 | CHRYSLER | TOWN & COUNTRY | ALL TRIM LEVELS |
| 2007-2014 | DODGE | AVENGER | ALL TRIM LEVELS |
| 2009-2012 | DODGE | CALIBER | ALL TRIM LEVELS |
| 2008-2014 | DODGE | CHALLENGER | ALL TRIM LEVELS |
| 2008-2010 | DODGE | CHARGER | ALL TRIM LEVELS |
| 2008-2011 | DODGE | DAKOTA | ALL TRIM LEVELS |
| 2008-2009 | DODGE | DURANGO | ALL TRIM LEVELS |
| 2008-2020 | DODGE | GRAND CARAVAN | ALL TRIM LEVELS |
| 2009-2010 | DODGE | JOURNEY | ALL TRIM LEVELS |
| 2008 | DODGE | MAGNUM | ALL TRIM LEVELS |
| 2007-2011 | DODGE | NITRO | ALL TRIM LEVELS |
| 2009-2012 | DODGE | RAM TRUCK | ALL TRIM LEVELS |
| 2008-2010 | JEEP | COMMANDER | ALL TRIM LEVELS |
| 2009-2017 | JEEP | COMPASS | ALL TRIM LEVELS |
| 2017 | JEEP | COMPASS | CLASSIC |
| 2008-2010 | JEEP | GRAND CHEROKEE | ALL TRIM LEVELS |
| 2008-2013 | JEEP | LIBERTY | ALL TRIM LEVELS |
| 2009-2017 | JEEP | PATRIOT | ALL TRIM LEVELS |
| 2007-2017 | JEEP | WRANGLER | ALL TRIM LEVELS |
| 2018 | JEEP | WRANGLER | JK |
| 2007-2017 | JEEP | WRANGLER UNLIMITED | ALL TRIM LEVELS |
| 2018 | JEEP | WRANGLER UNLIMITED | JK |
| 2008-2009 | MITSUBISHI | RAIDER | ALL TRIM LEVELS |
| 2013-2015 | RAM | C/V | ALL TRIM LEVELS |
| 2010-2012 | RAM | RAM TRUCK | ALL TRIM LEVELS |
| 2009-2013 | VOLKSWAGEN | ROUTAN | ALL TRIM LEVELS |
Support
Find the answers to many common questions:
*********************************
Warranty Information
We have a 30-day easy return policy for all purchases.
We provide a shipping label for defective products upon your return request at absolutely no cost to you. Non-defective products will not receive a shipping label and the consumer will be responsible for all shipping costs.
Stinger Off-Road products are warrantied against defects in materials One (1) Year from purchase date. Stinger Off-Road will, at its discretion, replace any products that exhibit defects in materials and/or workmanship during the warranty period. Assessments of defective parts are performed before replacements are shipped or refunds are released.
Please hold on to your order confirmation! All warranty service requires original sales receipt documentation with Order Number. The warranty only applies to the original purchaser.
Note: Products purchased from unauthorized dealers are not covered under warranty.
Warranty Limitations
Units found to have physical or liquid damage caused by use abuse or improper installation may be void of warranty.
