Completely Transform & Upgrade Your Jeep Wrangler JK (2007-2018) Stereo System
The STH10JK is an all-inclusive dash and multimedia upgrade for your Jeep Wrangler JK (models 2007-2018). Experience your media with over 16.7 million colors on a beautiful, 10-inch capacitive, floating touchscreen.
Packed with media features like Android Auto and Apple CarPlay, hands-free Bluetooth, SiriusXM-ready, and HDMI, stay entertained whether you're taking a road trip or just on your daily commute. And with safety features like 4 camera inputs and integrated GPS (microSD card sold separately), you can rest easy knowing we've got your back.
Features
- 10-inch 1024 x 600 HD digital capacitive touchscreen featuring 16.7 million colors
- Apple CarPlay
- Google Android Auto
- SiriusXM-Ready with Replay (SiriusXM Connect Vehicle Tuner and Subscription required)
- AM/FM radio - PTY / RT information
- High power 4 x 50W peak built-in amplifier
- 4V 6ch RCA audio outputs with subwoofer control
- Toslink (Optical) Variable Audio Output<br>
- 15 Band Adjustable EQ with 3 user presets for each audio source
- 1 HDMI rear input
- 2 USB rear inputs 1.5amp output
- Handsfree Bluetooth 4.2 A2DP with aptX
- Built-in microSD card slot for optional iGO Navigation
- 4 Camera Video inputs with wired triggers
- Mic Audio input from rear camera
- Hardwired remote control ready (Steering Wheel Controls)
- Customizable illumination colors and display backgrounds
- Shallow 1DIN chassis mounting design
What's In The Box
- Stunning 10-inch touchscreen display and infotainment system
- All-in-one Jeep radio replacement interface that retains your factory steering wheel controls, amplifier, and more
- Factory Jeep Wrangler antenna adapter
- SiriusXM Adaptor (allows you to retain factory-installed SiriusXM antenna, tuner sold separately: SXV300V1)
- Custom-fit Jeep Wrangler JK radio dash kit
- Flush mountable, dual USB ports
- STH10JK Installation Guide
Specifications
GENERAL
-
Recording Resolution: 1024 x 600
-
Screen Size: 10 inches
-
Model Number: STH10JKB
-
UPC: 609098833103
-
Manufacturer's Warranty - Parts: 1 year
-
Operating Voltage: 9.0VDC to 18VDC
-
Grounding system; Negative Ground
-
Max current consumption: 10A fused
DIMENSIONS
-
Radio Module: 178 mm x100 mm x 116 mm (W x H x D)
-
Display: 247.2 mm x 180.6 mm x 48.5 mm (W x H x D)
DISPLAY
-
10-inch Diagonal
-
16:9 aspect ratio
-
1024 x 600
-
Pixels: 1,843,200
-
Active area 222.72 (W) x 125.28 (H) mm
-
Operating Temperature (C) -20° to 70°
AUDIO
-
Peak power output: 50W x 4ch/4Ω
-
Load impedance: 4Ω nominal / 2Ω allowable
-
Continuous power output: 25W x 4ch/4Ω 20Hz to 20KHz, 1%THD at 14.4V
-
Audio output level (max): 4.0V preout
-
EQ: (15-band) 25Hz/40Hz/63Hz/100Hz/160Hz/250Hz/400Hz/ 630Hz/1KHz/1.6KHz/2.5KHz/4KHz/6.3KHz/ 10KHz/16KHz
-
Gain: ±12dB (2dB/step)
-
HPF: 25Hz/40Hz/63Hz/80Hz/100Hz/160Hz/250Hz
-
Slope: 6dB, 12dB, 18dB
-
Subwoofer Preout LPF: 25Hz/40Hz/63Hz/80Hz/100Hz/160Hz/250Hz
-
Slope: 6dB, 12dB, 18dB
-
Gain: -14dB to 7dB (1dB/step)
-
Phase: 0 or 180
-
Speaker level: ±9dB (1dB/step)
-
Time Alignment: 0 to 133 step (inch/ms)
FM TUNER
-
87.9MHz to 107.9MHz
-
Usable sensitive 0dB (mono S/N: 30dB)
-
SNR: 65dB
AM TUNER
-
530KHz to 1710KHz
-
Usable sensitive 0dB (mono S/N:20dB)
-
SNR 58dB
USB
- USB 2.0
- Max current supply 1.5A
- USB Class: MSC (Mass Storage Class), and MTP (Media Transfer Protocol)
- File system: FAT32, NTFS
BLUETOOTH
-
V4.2 dual
-
4dBm Class2
-
2.4GHz to 2.48GHz
CAMERA(S) VIDEO INPUTS
-
NTSC OR PAL video formats
HDMI INPUT
-
Supported HDMI Resolutions: 640*480p, 720*480p, 1280*720p, 1920*1080i, 1920*1080p
TOSLINK (OPTICAL)
-
Output: 48khz Variable
BACKGROUND IMAGE (USER)
-
File Format: JPG / PNG
-
Resolution: 1024 x 600
-
File size is not limited
AUDIO/VIDEO FORMATS AUDIO
-
MPEG-1 Audio Layer-3 (.mp3)
-
FLAC (.flac)
-
MPEG-2 Advanced Audio (.aac)
-
MPEG-4 Audio (.m4a)
-
Windows Audio (.wav)
-
OGG Audio (.ogg)
VIDEO
-
QuickTime (.mov)
-
MPEG-4 Video (.mp4)
-
Microsoft AVI (.avi)
-
MPG Video (.mpg)
-
MPEG Video 1/2 (.mpeg)
-
VOB DVD (.vob)
-
Flash Video (.flv)
-
JPEG (.jpg)
-
CompuServe GIF (.gif)
-
PNG (.png)
-
JPEG (.jpeg)
-
Bitmap(.bmp)
Support
Find the answers to many common questions:
*********************************
Warranty Information - Radio Replacement Kits & Bundles
Stinger Off-Road Radio Kits are warrantied against defects in materials One (1) Years from purchase date. Stinger Off-Road will, at its discretion, repair or replace any products that exhibit defects in materials and/or workmanship during the warranty period. Assessments of defective parts are performed before replacements are shipped or refunds are released.
Please hold on to your order confirmation! All warranty service requires original sales receipt documentation with Order Number. The warranty only applies to the original purchaser.
Note: Products purchased from unauthorized dealers are not covered under warranty.
Warranty Limitations
Units found to have physical or liquid damage caused by use abuse or improper installation may be void of warrant
