Overview
Description
Transform your Toyota Tacoma with the HEIGH10 radio kit! This all-inclusive dash & multimedia upgrade will take your infotainment to the next level. With an HD 10" touch screen head unit, a vehicle-specific interface to keep your OEM features, and featuring Bluetooth, Apple Carplay, and Android Auto you will experience a new life of luxury. This kit will come with everything you need for an easy installation!
Features
-
Gain Total Access to your Smartphone: Compatible with Apple CarPlay and Android Auto (wired connection), to make it possible to access map navigation, phone contacts, emails, notifications, music, and much more.
-
HD Touch Screen and Bluetooth Function: 10” high-definition capacitive touch screen supports Bluetooth handsfree calling and auto streaming will give you a fantastic experience.
-
Experience Versatile and More Detailed Sound Experience: Allows for more audio enhancements than any factory radio.
-
Help Reduce Risk with Multiple Camera Inputs: The HEIGH10 kit allows for up to four camera inputs via camera mode display.
-
Add Optional Integrated Navigation: Add on an iGo navigation SD card (sold separately) to enhance any driving experience by having 1000’s of built-in waypoints as well as landscape data at your fingertips.
-
Includes Everything you Need for Installation: Beautiful 10 inch touch screen, interface that retains OEM steering wheel controls, OEM antenna adapter, custom-fit dash kit, dual USB ports, and an installation guide.
- Media Features: Android Auto, Apple CarPlay, hands-free Bluetooth, SiriusXM-ready, and HDMI. And with safety features like 4 camera inputs and integrated GPS (microSD card sold separately).
What's In The Box
- 10 inch touch screen display and infotainment system
- RadioPro Interface for Toyota Tacoma (2016-2021)
- Toyota Tacoma radio dash kit (SR-TAC16H)
- Antenna adapters for satellite and AM/FM radio
- SiriusXM Adaptor (retain factory-installed SiriusXM antenna)
- Tuner sold separately & not on Stinger Off-Road: SXV300V1
- Custom-fit Toyota Tacoma radio dash kit
- Hardware kits
- USB retention cable
- Install Manual
- User Guide
Specifications
GENERAL
| Model Number | RB10TAC16B |
| Mounting Design | Single Din |
| Recording Resolution | 1024 x 600 |
| Screen Size | 10" |
| UPC | 609098833196 |
| Manufacturer's Warranty | 1 year |
| Operating Voltage | 9.0VDC to 18VDC |
| Grounding system | Negative Ground |
| Max Current Consumption | 10A fused |
DIMENSIONS
| Radio Module | 178 mm x100 mm x 116 mm (W x H x D) |
| Display | 247.2 mm x 180.6 mm x 48.5 mm (W x H x D) |
DISPLAY
| Diagonal | 10 inch |
| Aspect Ratio | 16:9 |
| Resolution | 1024 x 600 |
| Pixels | 1,843,200 |
| Active Area | 222.72 (W) x 125.28 (H) mm |
| Operating Temperature | (C) -20° to 70° |
AUDIO
| Load Impedance | 4Ω nominal / 2Ω allowable |
| Continuous Power Output | 25W x 4ch/4Ω 20Hz to 20KHz, 1%THD at 14.4V |
| Audio output level (max) | 4.0V pre-out |
| EQ | (15-band) 25Hz/40Hz/63Hz/100Hz/160Hz/250Hz/400Hz/ 630Hz/1KHz/1.6KHz/2.5KHz/4KHz/6.3KHz/10KHz/16KHz |
| Gain | ±12dB (2dB/step) |
| HPF | 25Hz/40Hz/63Hz/80Hz/100Hz/ 160Hz/250Hz |
| Slope | 6dB, 12dB, 18dB |
| Subwoofer Preout LPF | 25Hz/40Hz/63Hz/80Hz/100Hz/ 160Hz/250Hz |
| Slope | 6dB, 12dB, 18dB |
| Gain | -14dB to 7dB (1dB/step) |
| Phase | 0 or 180 |
| Speaker Level | ±9dB (1dB/step) |
| Time Alignment | 0 to 133 step (inch/ms) |
FM TUNER
| 87.9MHz to 107.9MHz |
| Usable sensitive 0dB (mono S/N: 30dB) |
| SNR: 65dB |
AM TUNER
| 530KHz to 1710KHz |
| Usable sensitive 0dB (mono S/N:20dB) |
| SNR 58dB |
USB
| Type | USB 2.0 |
| Max Current Supply | 1.5A |
| USB Class | MSC (Mass Storage Class), and MTP (Media Transfer Protocol) |
| File System | FAT32, NTFS |
BLUETOOTH
| V4.2 dual |
| 4dBm Class2 |
| 2.4GHz to 2.48GHz |
CAMERA(S) VIDEO INPUTS
| NTSC OR PAL video formats |
HDMI INPUT
| Supported HDMI Resolutions | 640*480p |
| 720*480p | |
| 1280*720p | |
| 1920*1080i | |
| 1920*1080p |
TOSLINK (OPTICAL)
| Output | 48khz Variable |
BACKGROUND IMAGE (USER)
| File Format | JPG / PNG |
| Resolution | 1024 x 600 |
| File size is not limited |
AUDIO/VIDEO FORMATS AUDIO
| MPEG-1 Audio Layer-3 (.mp3) |
| FLAC (.flac) |
| MPEG-2 Advanced Audio (.aac) |
| MPEG-4 Audio (.m4a) |
| Windows Audio (.wav) |
| OGG Audio (.ogg) |
VIDEO
| QuickTime (.mov) |
| MPEG-4 Video (.mp4) |
| Microsoft AVI (.avi) |
| MPG Video (.mpg) |
| MPEG Video 1/2 (.mpeg) |
| VOB DVD (.vob) |
| Flash Video (.flv) |
| JPEG (.jpg) |
| CompuServe GIF (.gif) |
| PNG (.png) |
| JPEG (.jpeg) |
| Bitmap(.bmp) |
Vehicle Fitment Guide
| Year(s) | Make | Model | Trim Level |
|---|---|---|---|
| 2016-2021 | TOYOTA | TACOMA | ALL TRIM LEVELS |
New Firmware
Click Here For Radio Firmware Download
Click Here For PDF Instructions On How To Update Your HEIGH10's Firmware
Click Here For a Video Walkthrough On How To Update Your HEIGH10 Firmware
Stinger UN1810 Update 09-03-21 Note: For Jeep JL/JT or RAM Integrated Kits, this release requires Radio Pro Advanced Firmware Version 14.
- Visit https://pac-audio.com/firmware-updates/ for the corresponding firmware download.
Release Notes:
- Fixes units getting stuck on the boot up screen.
- Adds AHD Camera compatibility (UN1810 HW REV 2.1.6.2 and higher)
- Adds onscreen RGB Light Control for Stinger ENLIGHT10 products.
- Adds compatibility for new hardware revisions.*
Support
Find the answers to many common questions:
*********************************
Warranty Information
We have a 30-day easy return policy for all purchases.
We provide a shipping label for defective products upon your return request at absolutely no cost to you. Non-defective products will not receive a shipping label and the consumer will be responsible for all shipping costs.
Stinger Off-Road products are warrantied against defects in materials One (1) Year from purchase date. Stinger Off-Road will, at its discretion, replace any products that exhibit defects in materials and/or workmanship during the warranty period. Assessments of defective parts are performed before replacements are shipped or refunds are released.
Please hold on to your order confirmation! All warranty service requires original sales receipt documentation with Order Number. The warranty only applies to the original purchaser.
Note: Products purchased from unauthorized dealers are not covered under warranty.
Warranty Limitations
Units found to have physical or liquid damage caused by use abuse or improper installation may be void of warranty.
